Feature | November 26, 2013

Diamond Flaws Pave Way for Nanoscale MRI

mri systems contrast media diamonds nanodiamonds cambridge
November 26, 2013 — Researchers say they have achieved enough coherence of the magnetic moment inherent in the defects of miniscule diamond fragments to harness their potential for precise quantum sensors in a material that is biocompatible.

Nanoscopic thermal and magnetic field detectors, which can be inserted into living cells, could enhance our understanding of everything from chemical reactions within single cells to signaling in neural networks and the origin of magnetism in novel materials.

Atomic impurities in natural diamond structure give rise to the color seen in rare and coveted pink, blue and yellow diamond. But these impurities are also a major research focus in emerging areas of quantum physics.

One such defect, the nitrogen-vacancy center (NVC), consists of a gap in the crystal lattice next to a nitrogen atom. This system tightly traps electrons whose spin states can be manipulated with extreme precision.

Electron coherence, the extent to which the spins of these particles can sustain their quantum mechanical properties, has been achieved to high levels in the NVCs of large “bulk” diamonds, with coherence times of an entire second in certain conditions — the longest yet seen in any solid material.

However, in nanodiamonds — nanometer-sized crystals that can be produced by milling conventional diamond — any acceptable degree of coherence has, until now, been elusive.

Nanodiamonds offer the potential for both extraordinarily precise resolution, as they can be positioned at the nano-scale, and biocompatibility, as they have can be inserted into living cells. But without high levels of coherence in their NVCs to carry information, these unique nanodiamond benefits cannot be utilized.
By observing the spin dynamics in nanodiamond NVCs, researchers at Cavendish Laboratory, University of Cambridge, identified that it is the concentration of nitrogen impurities that impacts coherence rather than interactions with spins on the crystal surface.

By controlling the dynamics of these nitrogen impurities separately, they increased NVC coherence times to a record 0.07 milliseconds longer than any previous report, an order of significant magnitude that puts nanodiamonds back in play as an extremely promising material for quantum sensing. The results were published the journal Nature Materials.

"Our results unleash the potential of the smallest magnetic field and temperature detector in the world,” said Helena Knowles, M.Sc. and researcher on the study. “Nanodiamond NVCs can sense the change of such features within a few tens of nanometers — no other sensor has ever had this spatial resolution under ambient conditions. We now have both high spin coherence and spatial resolution, crucial for various quantum technologies."

Dhiren Kara, Ph.D. and researcher on the study, pointed out that the nanodiamond's biocompatibility can provide non-invasive optical access to magnetic changes within a living cell — essentially the ability to perform magnetic resonance imaging (MRI) and detect, for instance, a cell's reaction to a drug in real time.

"We may also be able to answer some key questions in material science, such as magnetic ordering at the edges of graphene or the origin of magnetism in oxide materials," said Kara.

"The pursuit of simultaneous high NVC coherence and high spatial resolution, and the fact that nanodiamonds couldn't deliver on this promise until now, has required researchers to invest in alternative means including advanced nanofabrication techniques, which tends to be both expensive and low-yield,” said Mete Atature, Ph.D. and director of the research. “The simplest solution — feasible and inexpensive — was in front of us the whole time."

For more information: www.phy.cam.ac.uk, www.rsna.org
